RESEARCH PROJECT - Mod. 71 and Mod. 71/84 - Craig Brown

[Loewe]

That's a nice example of an export ŒWG 71. These have German acceptance on the barreled receiver, but not the stock. Paul is still tracking them though, so thanks for the report!

Thanks for the headsup, I never go to Gunboards these days, I do not even have the log-in details... if someone can gather the details in the format of the research thread, Chris or I can add it to the thread, no need to lift the photos and post them here. The purpose is purely establishing trends of observed production, mostly ranges, breaks year to year, and various patterns developed during production (units, modifications etc..)



[Amberg]

From an old Hermann Historica auction:

http://www.hermann-historica-archiv.de/auktion/hhm57.pl?f=NR&c=&t=temartic_S_GB&db=kat57_s.txt

G.A.G. Mod. 79
"V.C.S. Suhl", 1880
#1311



[mrfarb]

I see you are still collecting data. 1886 manufacturing date. An 3207 with 3.G.G.R.E.1.79 unit mark.



[Warrior1354]

I see you are still collecting data. 1886 manufacturing date. An 3207 with 3.G.G.R.E.1.79 unit mark.

Glad to see you get that one home Mike! It was a nice rifle buddy.



[chrisftk]

I see you are still collecting data. 1886 manufacturing date. An 3207 with 3.G.G.R.E.1.79 unit mark.

Thanks Mike- Appreciate you taking the time to post that. I'll add it to the list.

This is bracketed nicely between two others from the same unit. Love it when that happens.



[Steve Medlock]

My 71/84 is 1888 Spandau 2326 with no regimental markings



[kar66]

Paul there is a H marked 71 Mauser on Gunbroker. It just went off the number is 1003172631. It is mostly matching, but the stock and buttplate.



[tsopmgb]

my all matching Gew 71. 1875 Steyr 1207P



[Cyrano4747]

Not as pretty as most of the others in here, but here's my WMO. I.G. Mod 71, 1878, C/W, SN 2894G, no unit markings.

Matching except for the bolt head and the trigger guard, which is one of the wartime steel replacements.



[PrayingMantis]

Not as pretty as most of the others in here, but here's my WMO. I.G. Mod 71, 1878, C/W, SN 2894G, no unit markings.

Matching except for the bolt head and the trigger guard, which is one of the wartime steel replacements.

Now that deserves its own thread.



[Cyrano4747]

Now that deserves its own thread.

Really? I never thought of it as too special, WMO's aren't easy to come by but they're not impossible either. Condition is pretty meh. Mostly I got it to try and round out my MWO collection.

GB pick up maybe two years back for $700.

edit: now the REAL challenge is going to be finding a WMO 71/84, or equivalent. A Turkish 1887 would also fill that niche as far as I'm concerned, although who am I kidding I'll end up trying to get both eventually. Still kicking myself for passing on a 1887 a few months back for $1.2k. I've got a pretty nice Spandau 71/84 as a place holder, but it's not the same.



[PrayingMantis]

Really? I never thought of it as too special, WMO's aren't easy to come by but they're not impossible either. Condition is pretty meh. Mostly I got it to try and round out my MWO collection.

GB pick up maybe two years back for $700.

Definitely worth it. The fact alone that it’s Wurttemberg accepted makes it worthy of detailed study. Plus it’s looks very original, I’d take more original over higher condition any day.



[Adirondneck]

For the database- 71/84 Spandau 1888 Serial No. 2137, no unit mark.



[Stormy]

Hey folks, my addition for the database.

1888 Spandau 7726 (I.G. Mod. 71/84.) unit: none

My example has a mismatched bolt and a few mismatched screws (xx12, xx25, xx29, xx01).



[Loewe]

Now that deserves its own thread.

I agree completely! WMO is quite elusive, 1878 only 3 recorded, one a German auction (which means one or two pictures), another Storz (which meager details at best..); really any WMO, even a wartime G98, deserves a group of pictures as even when common (like WMO/17) they often are interesting for other reasons.

I will have to do some catching up on updating these recent posts, been neglectful here dealing with personal drama common to all eventually, but a minimal amount of maintenance is needed here. I will try to update the trends on the relevant updates this week.



[kar66]

Paul there is another H marked 71 Mauser on GB No. 1018291222.



[Loewe]

Paul there is another H marked 71 Mauser on GB No. 1018291222.

I will check it out and update the database thread while the wife is slaving away over the turkey tomorrow!



[siegersallee]

Hi folks,
I have been reading through this thread and hope it is still being monitored by the person requesting the data.

I have an 1871 carbine and an 1871/84 infantry gewehr.

The M1871 KAR is all-matching (screws and all parts), dated 1877, SN:1434, manufacturer: Spanganberg and Sauer SUHL, unit marked: B.A.M.II.3.52.
The M1871/84 IG is all-matching (screws and all parts), dated 1888, SN: 87124, manufacturer: Amberg, unit marked: B.12.R.E.3.151.


I am actively looking for an 1871 IG all-matching, unit-marked, highly-collectible condition; but, so far, I have not found one. If anyone reading this is so blessed please hit me up and see if we can do a deal.

Best Regards to all,
Richard



K. Mod 71
View attachment 391933View attachment 391934




IG Mod 71/84
appologies for the fuzzy pictures here. I need to take newer ones. These two rifle full length shots were given to me by the seller about 10 years ago using his phone camera.



[Cyrano4747]

That's a gorgeous kar 71. You don't often see them in that kind of condition.



[PrayingMantis]

Hi folks,
I have been reading through this thread and hope it is still being monitored by the person requesting the data.

I have an 1871 carbine and an 1871/84 infantry gewehr.

The M1871 KAR is all-matching (screws and all parts), dated 1877, SN:1434, manufacturer: Spanganberg and Sauer SUHL, unit marked: B.A.M.II.3.52.
The M1871/84 IG is all-matching (screws and all parts), dated 1888, SN: 87124, manufacturer: Amberg, unit marked: B.12.R.E.3.151.


I am actively looking for an 1871 IG all-matching, unit-marked, highly-collectible condition; but, so far, I have not found one. If anyone reading this is so blessed please hit me up and see if we can do a deal.

Best Regards to all,
Richard

These are both exceptional looking Mauser 71s. While i'm sure Paul will add these to the 71 research, if you do individual threads for them i would love to add them to the reference.
